92-00 HONDA CIVIC 36MM SWAP SPINDLE

INSANE SHAFTS 36MM SWAP SPINDLES ARE THE PERFECT SOLUTION FOR YOUR HIGH POWERED ENGINE SWAPS. MADE TO FIT OEM AND THE INSANE SHAFTS LINE OF 36MM, BIG SPLINED AXLES WHICH ARE PROVEN TO HANDLE HIGH HORSEPOWERED VEHICLES THROUGH THE TOUGHEST CONDITIONS. UTILIZES OEM WHEEL BEARING AND OEM BRAKE ROTOR MOUNTING DIMENSIONS FOR A TRUE BOLT-ON DESIGN. CNC MACHINED OUT OF HIGH STRENGTH CHROMOLY STEEL AND INCLUDES ARP EXTENDED WHEEL STUDS. SOLD IN PAIRS. WHEEL BEARINGS AND BRAKE ROTORS NOT INCLUDED. Specifications:

• APPLICATION: 1992- 2000 HONDA CIVIC
• WHEEL BOLT PATTERN: 4 X 100
• WHEEL BEARING I.D.: 38MM
• DISC BRAKE SIZE: 240MM (9.456")
• WHEEL STUD LENGTH: 2.50"
• WHEEL STUD THREAD: M12 X 1.5
• REPLACES OEM PART # 44600-S04-980

92-00 HONDA CIVIC / 94-01 INTEGRA 36MM SWAP SPINDLE

INSANE SHAFTS 36MM SWAP SPINDLES ARE THE PERFECT SOLUTION FOR YOUR HIGH POWERED ENGINE SWAPS. MADE TO FIT OEM AND THE INSANE SHAFTS LINE OF 36MM, BIG SPLINED AXLES WHICH ARE PROVEN TO HANDLE HIGH HORSEPOWERED VEHICLES THROUGH THE TOUGHEST CONDITIONS. UTILIZES OEM WHEEL BEARING AND OEM BRAKE ROTOR MOUNTING DIMENSIONS FOR A TRUE BOLT-ON DESIGN. CNC MACHINED OUT OF HIGH STRENGTH CHROMOLY STEEL AND INCLUDES ARP EXTENDED WHEEL STUDS. SOLD IN PAIRS. WHEEL BEARINGS AND BRAKE ROTORS NOT INCLUDED. Specifications:

• APPLICATION: 1992- 2000 HONDA CIVIC / 1994-2001 ACURA INTEGRA
• WHEEL BOLT PATTERN: 4 X 100
• WHEEL BEARING I.D.: 43MM
• DISC BRAKE SIZE: 262MM (10.3228")
• WHEEL STUD LENGTH: 2.50"
• WHEEL STUD THREAD: M12 X 1.5
• REPLACES OEM PART # 44600-S04-A00

500HP 98-01 HONDA CRV M.T. AWD REAR

FAR MORE SUPERIOR THAN YOUR TYPICAL SWAP AXLES, INSANE SHAFTS AXLES ARE MADE OUT OF CHROMOLY STEEL THAT IS PUT THROUGH OUR PROPRIETARY ANNEALING AND HEAT TREATMENT PROCESS THAT IS CAPABLE IN HANDLING POWER DEMANDS OF UP TO 500 WHEEL HORSEPOWER. THESE AXLES ARE THE PERFECT ADDITION TO YOUR HIGH PERFORMANCE VEHICLE NEEDS. ALL INSANE SHAFTS AXLES INCLUDE REMOVABLE ABS RINGS (IF APPLICABLE) AND NEW SPINDLE NUTS. PLEASE CONTACT US FOR CUSTOM APPLICATIONS. APPLICATION: 98-01 CRV M.T/A.T. AWD REAR ENGINE: TRANSMISSION: INTERMEDIATE SHAFT:

Click here to purchase this axle in 1000HP

500HP 98-01 HONDA CRV M.T. AWD

FAR MORE SUPERIOR THAN YOUR TYPICAL SWAP AXLES, INSANE SHAFTS AXLES ARE MADE OUT OF CHROMOLY STEEL THAT IS PUT THROUGH OUR PROPRIETARY ANNEALING AND HEAT TREATMENT PROCESS THAT IS CAPABLE IN HANDLING POWER DEMANDS OF UP TO 500 WHEEL HORSEPOWER. THESE AXLES ARE THE PERFECT ADDITION TO YOUR HIGH PERFORMANCE VEHICLE NEEDS. ALL INSANE SHAFTS AXLES INCLUDE REMOVABLE ABS RINGS (IF APPLICABLE) AND NEW SPINDLE NUTS. PLEASE CONTACT US FOR CUSTOM APPLICATIONS. APPLICATION: 98-01 CRV M.T/A.T. AWD FRONT ENGINE: TRANSMISSION: INTERMEDIATE SHAFT:

Click here to purchase this axle in 1000HP

500HP 88-91 HONDA CIVIC AWD WAGON REAR

INSANE SHAFTS AXLES ARE FAR MORE SUPERIOR THAN YOUR TYPICAL SWAP AXLES. MADE FROM CHROMOLY STEEL THAT IS PUT THROUGH OUR PROPRIETARY ANNEALING AND HEAT TREATMENT PROCESS, THESE AXLES ARE CAPABLE IN HANDLING POWER DEMANDS OF UP TO 500 WHEEL HORSEPOWER AND ARE THE PERFECT ADDITION TO YOUR HIGH PERFORMANCE VEHICLE NEEDS. ALL INSANE SHAFTS AXLES INCLUDE REMOVABLE ABS RINGS (IF APPLICABLE) AND NEW SPINDLE NUTS. PLEASE CONTACT US FOR CUSTOM APPLICATIONS. APPLICATION: 88-1991 HONDA CIVIC AWD WAGON REAR ENGINE: TRANSMISSION: INTERMEDIATE SHAFT:

Click here to purchase this set of axles in 1000HP To purchase these axles individually, follow these links: IS-022 / IS-023

1000HP 99-00 FORD MUSTANG COBRA REAR

THE ULTIMATE IN HIGH PERFORMANCE CV AXLES, INSANE SHAFTS 1000HP AXLES ARE MADE FROM CHROMOLY STEEL THAT IS PUT THROUGH OUR PROPRIETARY ANNEALING AND HEAT TREATMENT PROCESS THEN CRYOGENICALLY TREATED TO PROVIDE MORE STRENGTH TO HANDLE TODAYS HIGH HORSEPOWER VEHICLE DEMANDS. CAPABLE IN HANDLING UP TO 1000 WHEEL HORSEPOWER, THESE AXLES HAVE BEEN REAL WORLD TESTED AND PROVEN TO HANDLE EXTREME CONDITIONS ON OR OFF THE TRACK. ALL INSANE SHAFTS AXLES INCLUDE REMOVABLE ABS RINGS (IF APPLICABLE) AND NEW SPINDLE NUTS. PLEASE CONTACT US FOR CUSTOM APPLICATIONS. APPLICATION: 99-2000 FORD MUSTANG COBRA REAR ENGINE: TRANSMISSION: INTERMEDIATE SHAFT: N/A

Click here to purchase this set of axles in 500HP To purchase these axles individually, follow these links: IS-302-D

1000HP 01-04 FORD MUSTANG SVT COBRA REAR

THE ULTIMATE IN HIGH PERFORMANCE CV AXLES, INSANE SHAFTS 1000HP AXLES ARE MADE FROM CHROMOLY STEEL THAT IS PUT THROUGH OUR PROPRIETARY ANNEALING AND HEAT TREATMENT PROCESS THEN CRYOGENICALLY TREATED TO PROVIDE MORE STRENGTH TO HANDLE TODAYS HIGH HORSEPOWER VEHICLE DEMANDS. CAPABLE IN HANDLING UP TO 1000 WHEEL HORSEPOWER, THESE AXLES HAVE BEEN REAL WORLD TESTED AND PROVEN TO HANDLE EXTREME CONDITIONS ON OR OFF THE TRACK. ALL INSANE SHAFTS AXLES INCLUDE REMOVABLE ABS RINGS (IF APPLICABLE) AND NEW SPINDLE NUTS. PLEASE CONTACT US FOR CUSTOM APPLICATIONS. APPLICATION: 01-2004 FORD MUSTANG SVT COBRA REAR ENGINE: TRANSMISSION: INTERMEDIATE SHAFT: N/A

Click here to purchase this set of axles in 500HP To purchase these axles individually, follow these links: IS-301-D

HONDA/ACURA K-SERIES MT INTERMEDIATE SHAFT

K-SERIES MT INTERMEDIATE SHAFTS

INSANE SHAFTS 2002-2005 HONDA CIVIC, 2002-2006 ACURA RSX MT, 2002-2006 CRV MT, 2003-2010 ELEMENT MT 500 HP

HONDA/ACURA B-SERIES INTERMEDIATE SHAFT

B-SERIES MT INTERMEDIATE SHAFTS

INSANE SHAFTS B-SERIES MT 94-2001 INTEGRA HYDRO 99-2000 CIVIC SI 500 HP CV AXLES

1988-2001 CIVIC/INTEGRA B-SERIES HYDRO

500HP: FAR MORE SUPERIOR THAN YOUR TYPICAL SWAP AXLES, OUR 500HP AXLES ARE MADE OUT OF CHROMOLY STEEL THAT IS PUT THROUGH OUR PROPRIETARY ANNEALING AND HEAT TREATMENT PROCESS THAT IS CAPABLE IN HANDLING POWER DEMANDS OF UP TO 500 WHEEL HORSEPOWER. THESE AXLES ARE THE PERFECT ADDITION TO YOUR HIGH PERFORMANCE VEHICLE NEEDS. 1000HP: THE ULTIMATE IN HIGH PERFORMANCE CV AXLES, INSANE SHAFTS 1000HP AXLES ARE MADE FROM CHROMOLY STEEL THAT IS PUT THROUGH OUR PROPRIETARY ANNEALING AND HEAT TREATMENT PROCESS THEN CRYOGENICALLY TREATED TO PROVIDE MORE STRENGTH TO HANDLE TODAY’S HIGH HORSEPOWER VEHICLE NEEDS. CAPABLE IN HANDLING UP TO 1000 WHEEL HORSEPOWER, THESE AXLES HAVE BEEN REAL WORLD TESTED AND PROVEN TO HANDLE EXTREME CONDITIONS ON OR OFF THE TRACK. ALL INSANE SHAFTS AXLES INCLUDE REMOVABLE ABS RINGS (IF APPLICABLE) AND NEW SPINDLE NUTS. PLEASE CONTACT US FOR CUSTOM APPLICATIONS. APPLICATION: 90-2001 INTEGRA (DA,DC) /88-2000 CIVIC/CRX/DEL SOL (EF, EG, EK) WITH B-SERIES SWAP ENGINE: B16/B18/B20 TRANSMISSION: B-SERIES HYDRAULIC INTERMEDIATE SHAFT: B-SERIES HYDRAULIC (MALE) PART NUMBERS:

• 500HP: IS-005-IS-006
• 1000HP: IS-005-IS-006-D
